Data Collection

nanodac™ Recorder / Controller

The ultimate in graphical recording combined with PID control and setpoint programsnanodac Recorder / Controller

Eurotherms nanodac™ recorder/controller offers the ultimate in graphical recording combined with PID control for a box of its size. The compact ¼ DIN panel mount unit offers four high accuracy universal inputs for data recording and PID control. This secure data recording device with accurate control is enhanced by a full colour, ¼ VGA display to bring a crystal clear operator interface to even the smallest of machines.

 nanodac - The ultimate in graphical recordingDescription

  • Precision analog batch recording
  • EtherNET/IP Client or Server mode
  • 3 x Isolated DC Outputs (DDD)
  • Washdown Front
  • Crystal clear, colour display
  • Data Acquisition and Recording
  • PID Control Loops



Features:
AMSE2750E - Yes
Analogue IP/OP - In: 8 Out: 3
Annotation - Yes
Auditor Features - No
Batch - No
Contact Inputs - Yes
Control Algorithms - Single, Cascade, User Wired
Control Loops - 2
Counters - 2
Customer Screens - No
Digital Comms - Modbus TCP/IP Master/Salve EtherNet/IP Client/Server
Digital IP/OP - In: 4 Out: 5
Ethernet/FTP - Yes
Graphic Display - 3.5" TFT 320 x 240 pixels
Groups - 1
Inputs - 4
Mathematics - Yes
Maths Equation - 17 Calculations
Network Addressing - DHCP, Fixed IP
PC Configuration - Yes
Protection - IP65, NEMA12
Recording Speed - 8Hz
Relay Outputs - Yes
Remote Viewing - Yes
Reports - No
Review of History (on screen) - Yes
Special Features - Relative Humidity, Washdown Faceplate, User Wires, Carbon Potential
Timers/Counters/Totals - 4 / 15 / 15
Totalizers - Yes
Trend Speed - 8 Hz
USB - 1
Input Type - TC, RTD, mV, mA
PV Accuracy - <0.1%
IP Rating - IP65, NEMA12
Display Type - 3.5" TFT Color 320 x 240 pixels
Control Types - On/Off, PID, VP
Supply Voltage - 24V dc/ac 85-274V ac
SP Programmer - 100 Programs,, 25 Segments, Local/USB/FP
Timers - Yes

Paper Chart Recorders

392 Circular Chart Recorder

Eurotherm's 392 Paper Chart Recorder is a user configurable 1,2,3 or 4 pen, continual trace, 100mm calibrated width circular chart instrument.  Current status information is presented on a front panel mounted, high visibility, vacuum fluorescent display.

The modular construction and compact design ensure that it is convenient to locate, while being easy to maintain and upgrade. This model is idea for:  Environmental applications, water and waste water, boilers, as well as food and beverage applications.

Features

  • Standard linearization
  • Custom curve
  • 40 character VFD display
  • User configurable
  • Math functions
  • Totalizers with 9-digit readout
  • Single and dual output controllers
  • Configurable alarms
  • Relay alarm outputs
  • Parameter retransmission
