Barcode Systems

Leuze - Safe bar code positioning system FBPS 600i

For Safe Position Detection with Just One Device up to PLe

The world's first safety bar code positioning system, FBPS 600i, requires just one sensor for safe position detection. The device is connected to a safe evaluation unit – e.g. a frequency inverter – via two SSI interfaces and is suitable for applications up to performance level PL e. As a result, safety functions can be implemented extremely easily and the time and effort required for installation and servicing is reduced.

Advantages

  • Safe position detection with just one device up to PL e
  • Extremely easy implementation of the safety functions
  • Low space requirements and reduced installation effort
  • Short fault reaction time of 10 ms for use on fast stacker cranes
  • Extremely robust, mechanically resilient and UV-resistant bar code tape
  • Wide working range of 50 to 170 mm and the well-thought-out fastening concept ensure simple mounting and integration


Leuze - BPS 300i Bar Code Positioning System

The read head of the bar code positioning system is moved along a bar code tape. It calculates the absolute position data in the direction of travel with millimeter accuracy up to a distance of 10,000m. The bar code tape is extremely simple to use and can be bonded both in straight lines and in curves. Maximum flexibility, simple mounting, transparent diagnosis as well as a large selection of integrated interfaces are the strengths of this system. The BPS 300i is the second generation of bar code positioning and sets standards both in performance characteristics and in handling. The new "availability control" function allows diagnosis to be performed during operation. The large working range of +/-60 mm makes mechanical installation easier and precise measurements possible even if the distance to the tape varies.




Baumer - The New VeriSens® ID Series

Identifies Matrix Codes and Barcodes Including GS1

The ID series can recognize multiple codes simultaneously and text (including dot matrix text) even without time consuming font training. Up to 32 features can be checked at the same time. Illumination and a 10 mm or 16 mm lens are already included – the sensors only need to be parameterized on a PC.

Doubled productivity: VeriSens® models ID510
With the new vision sensor models, users benefit from doubled productivity in image-based quality inspection. In many applications, enhanced processing speed will cut image processing time in half or significantly enhance inspection scope. Sophisticated code reading algorithms improve reading reliability under industrial conditions. Integrated Industrial Ethernet allows for efficient interfacing with reduced integration and cabling effort.

Key FeaturesBaumer Model ID Series

  • IP67 metal housing for industrial environment
  • Intuitive configuration via PC (Ethernet)
  • Built-in LED illumination
  • Integrated 10mm or 16mm lens (16mm only ID-100)
  • Selected models with integrated Industrial Ethernet
  • Five digital I/Os or three digital outputs and RS485 (ID-100)

Models
